PS200 - A 4-Gas Detector
A robust and accurate portable gas detector, the Personal Surveyor (PS200 Series) provides unrivalled protection in confined space applications with audible and visual alarms in the event of exposure to flammable or toxic gases.
Detecting and displaying up to 4 gases simultaneously, PS200 is suitable for a host of applications in a variety of industries. The PS200 can be configured to detect a combination of Methane, Oxygen, Carbon Monoxide, Hydrogen Sulphide, as well as other flammable gases.
Pre-entry checking can be carried out with the optional internal sampling pump, and diffusion operation ensuring maximum battery life in confined spaces
Key Benefits
- Simple 1-button operation
- Measures up to 4 gases:
- CH4 – Methane (LEL)
- O2 – Oxygen
- CO – Carbon Monoxide
- H2S – Hydrogen Sulphide
- Other flammable gases, available on request
- Audible, visual and vibrating alarms
- Internal pump (optional)
- Lightweight yet robust construction
- Sensor integrity checking
- Ease of maintenance
- 2-YR WARRANTY
Applications
- Personal safety in confined space – CH4/O2/CO/H2S hazards
- General safety in confined space
- Shipping – general
- Shipping – fumigant
- Breweries
- Plant shutdown
- Permit to work systems
- Pressurised tunnelling
- Fleet auxiliary
Specifications
| LEL | 0-100% | |||||||||
| O2 | 0-25% | |||||||||
| CO | 0-1000ppm | |||||||||
| H2S | 0-100ppm | |||||||||
| Dimensions | 121 (H) x 59 (W) x 32 (D) mm | |||||||||
| Weight | 230g w/ Pump - 215g wo/ Pump | |||||||||
| Humidity | 0-95% RH non-condensing | |||||||||
| Temperature | 4 degF - 122 degF | |||||||||
| IP Rating | 67 | |||||||||
| Power | Li-Ion Battery | |||||||||
| Run Time (Diffusion) | > 14hrs | |||||||||
| Run Time (Pumped) | > 8hrs | |||||||||
| Charging Time | < 4hrs | |||||||||
| Alarms | LED / Audible / Vibration | |||||||||
| Certifications |
|
